By increasing the block size you are also increasing the “range” where the FECs can be applied. However, these unused FEC packets are useless for the following block. Why does this increase reliability? Very often, blocks are only mildly corrupted so that not all FEC packets will be needed.
#FPS SIDETALK FULL#
However, this increases the latency since it needs to be waited until a full block of data has been received before the transmission can begin. Changing the block lengths while keeping the coding rate constant: An increased block length can increase the reliability of a link without increasing the bandwidth.If your block size is 8 DATA packets then this would result in 4 FEC packets. A FEC ratio of 50% is roughly(!) comparable (in terms of reliability) to a retransmission rate of 2. Changing the coding rate while keeping block size constant: Increasing the number of FEC packets increases the reliability of the link at the expense of higher bandwidth.The block length is simply given by the -b parameter. The coding rate is defined by the ratio between DATA and FEC packets. There are two things to consider: The coding rate and the block length. The values of the parameters depend on your application. Otherwise the transmission does not work anymore. It is also important to note that both tx and rx need to agree on -b, -r and -f. The only difference is that packets now cannot be smaller than -f. This parameter is identical to the retransmission version in that it defines the size of a packet. Each block will be appended with -r FEC packets. -r This parameter has changed from number of retransmissions to number of FEC packets.So this parameter has more or less the same meaning as with the retransmission version -b This parameter describes the number of DATA packets per block.Only some parameters have now a different meaning: The basic usage of wifibroadcast has not changed. The new FEC feature has been merged into the default branch of wifibroadcast (together with the new fifo interface introduced here) It is no more important which packets are corrupted, only how many. Reliability: Since any DATA packet can be repair with any FEC packet, the chances of corruptions drop significantly.There the “smallest” bandwidth with redundancy would be +100% This could not have been archived with retransmission. Bandwidth: Since we used in the example above 4 FEC packets per 8 DATA packets, the bandwidth requirements are +50%.So we might be able to repair up to 4 DATA packets, regardless which ones of the 8 are affected. If now a DATA packet gets lost, it can be replaced by any of the 4 FEC packets.
#FPS SIDETALK CODE#
The FEC code now allows you to calculate an arbitrary number of FEC packets (that have the same size as the DATA packets). Lets assume we have a block size of 8 packets. Your data has to be divided into packets and a fixed number of them are grouped together to form a block. In the code Vandermonde matrices are used to perform the FEC. In addition, the code is fast enough to run on a Raspberry PI A+. And well, that is exactly what wifibroadcast does! The FEC code there was well written and easy to adopt for my use case. Some commentators suggested to take a look at udpcast, a tool that is able to transfer data over a lossy unidirectional link. We are sending a lot of packets so unlikely things can easily happen. For example, if you roll a million times, you could expect to see the sequence “1”-“2”-“3”-“4” nearly a thousandth times. The explanation is quite simple: If you roll a dice often enough, the likelihood of some strange combinations happening needs to be considered. Relieability: Although it seems unlikely that all N retransmissions of the same packet are lost that phenomenon existed.This is quite obvious: If you transmit each packet three times, you need three times the bandwidth. And this rate basically multiplied the net bandwidth. Bandwidth: The only parameter to increase the reliability was the retransmission rate.
This worked sufficiently well but had some issues: Each packet got sent several times, increasing the chance that at least one packet got through. Initially I implemented a simple retransmission.
After some months of testing and dozens of other people having also great experiences with wifibroadcast I was confident enough to start to “improve” things. While I agreed on these suggestions, my primary goal was to first create something that is usable to see if the idea behind wifibroadcast is worth following. This helps lowering the data rate and/or increasing the reliability of the transmission.Įarly after I published wifibroadcast there were suggestions on improving the forward error correction (FEC) mechanism.
This post introduces a new feature to wifibroadcast: Forward error correction.
